Stroke applicators 4114, 4116
Labels very small or midsized can be applied in real time from all sides
The pad locates in front of the peel-off plate. It picks up a label while it is being printed. Powered by a short stroke cylinder, the pad is brought into position in horizontal direction. The label is transferred to a product by a stroke cylinder. The length of the stroke cylinder defines the maximum distance of a product to the peel-off plate.
Tamp-on pad
Labels are precisely tamped on plane surfaces. Recessed levels are possible as well.
Tamp-on pad, providing a damping layer
When applying labels to hard surfaces, the noise level is reduced. It benefits also in cases of rough structures or little unevenness.
Tamp-on pad, providing a label stop
It enables small labels be applied exactly on spot to a product.
Blow-on pad
It benefits when labels have to be applied to sensitive surfaces or products in motion. Labels are blown on by a blast of air. Stroke cylinder adjustment enables bridging distances of 5 to 10 mm to the surface of a product.
Form pad
Labels are precisely applied to cylindric objects, inclined or curved surfaces. Curved form pads prevent from blistering on very smooth and plane surfaces. 200° maximum label wrapping on cylindric objects
Video: Hermes Q with applicator 4114 and form pad
Labels are applied precisely to cylindric objects, oblique or curved surfaces.
Want to learn more?
Ask for an offer free of charge and without obligation:
Learn more:
Designed for fully-automated print and apply processes in production lines.
The device is designed to use on a cab printer of the HERMES Q and Hermes+ series.
| Technical data | Tamp-on pad | Tamp-on pad, providing a damping layer |
Tamp-on pad, providing a label stop |
Blow-on pad | Form pad | |
|---|---|---|---|---|---|---|
| 4114, 4116 L/R 11 F | 4114, 4116 L/R 12 F | 4114, 4116 L/R 61 F | 4114 L/R 2100 | 4114, 4116 L/R 8800 | ||
| Label widths operating a HERMES Q2 mm Label widths operating a HERMES Q4/Q4.3 mm Label widths operating a HERMES Q6.3 mm |
4 - 58 | 10 - 58 | 10 - 58 | 10 - 58 | 10 - 58 | |
| 10 - 114 | 10 - 114 | 10 - 114 | 10 - 114 | 10 - 114 | ||
| 50 - 174 | 50 - 174 | 50 - 174 | - | 50 - 174 | ||
| Label heights operating a HERMES Q2 mm Label heights operating a HERMES Q4/Q4.3 mm Label heights operating a HERMES Q6.3 mm |
4 - 80 | 8 - 80 | 4 - 80 | 10 - 80 | 8 - 80 | |
| 8 - 80 | 8 -80 | 8 - 80 | 10 - 80 | 8 - 80 | ||
| 8 - 80 | 8 - 80 | 8 - 80 | - | 8 - 80 | ||
| State of a productin rest at the moment a label is applied in motion |
 |
|||||
| - | - | - | |
- | ||
| Label applications from the top from below from the side |
|
|||||
|
||||||
|
||||||
| Product heights uniform Product heights variable |
- | - | - | |
- | |
|
|
|
- | |
||
| Short stroke cylinder, horizontal mm | 10 | |||||
| Distance of a product to the bottom of the unit using a cylinder stroke of 200 up to mm cylinder stroke of300 up to mm cylinder stroke of 400 up to mm |
135 |
135 |
135 |
140 |
135 |
|
| 235 | 235 | 235 | 240 | 235 | ||
| 335 | 335 | 335 | 340 | 335 | ||
| Depth of a pad immersing F1) up to mm | 110 | 110 | 110 | - | - | |
| Weight of applicator using a cylinder stroke of 200 packaging excluded kg cylinder stroke of 300 packaging excluded kg cylinder stroke of 400 packaging excluded kg |
5 |
5 |
4114 5 |
4116 5 |
||
| 5.5 | 6 | 5.5 | 6 | |||
| 7 | 7.5 | 7 | 7.5 | |||
| Consumption of power W max. | 15 | |||||
| Compressed air bar | 4.5 | |||||
| Cycle rate2) labels/min approx. | 30 | 30 | 30 | 30 | 20 | |
- On the cover HERMES Q2/Q4/Q4.3 cut-out dimension F standard 60 mm, optional 100 mm, on r equest up to 110 mm
On the cover HERMES Q6.3 cut -out dimension F standard 25 mm, on request up to 110 mm - calculated using a stroke of 100 mm below the unit, labels 40 mm high, a print speed of 100 mm/s
Want to learn more?
Ask for an offer free of charge and without obligation:
Learn more:
-
Accessories and options provided for applicators
-
4.1 4.2 4.3 4.4 4.5 4.6 4.7 4.8 4.9 4.13 Pos Designation 3214 4114/16 4214 4414 4514 4712 3014/16 4014/16 4614 6114 5.13 Blow tube
5.14 Unit regulating compressed air
5.16 Unit regulating compressed air providing a shut-off valve - - - - - - - - - 5.17 Pressure-reducing valve - - - - - - -
Blow tube
to provide support air. To assist label transfer, the label is blown from below to the pad.
Provided for 2", 4" or 6" label applications
-
Unit regulating compressed air
4.5 bar default setting
Provided in a left-hand or right-hand design
Delivery includes a fine filter, a pressure control valve with a display, a hose to connect to an applicator's compressed air input and material to assemble the unit to a chassis or bracket.
-
Pressure-reducing valve
It reduces the pressure exerted by the stroke cylinder to the product.
Designed for applicators 4014/16, 4114/16, 4214, 4414
-
How to assemble a compressed air regulation unit
1 Chassis assembly
2 Bracket assembly
-
